As Built Drawing: Scan to CAD / LiDAR Point Cloud to BIM

At Triangle Engineers Ltd. (TEL), we are at the forefront of integrating the physical and digital worlds to enhance precision and efficiency in engineering and construction. Our Scan to CAD/BIM service leverages cutting-edge LiDAR technology to transform real-world environments into highly accurate and detailed digital assets, forming the foundation for superior project outcomes.

Bridging Reality and Digital Design

Our LiDAR Point Cloud to CAD/BIM service is a comprehensive solution that captures precise as-built data and converts it into intelligent 3D models. This process is essential for modern construction, renovation projects, and facility management, ensuring that your digital designs perfectly mirror the existing physical conditions. By eliminating guesswork and manual data collection, we empower your projects with unparalleled accuracy from the very beginning.

Our Process:

Precision at Every Step TEL's methodology ensures that we deliver the highest quality data and models, tailored to your project's specific needs. Our process includes:

High-Fidelity LiDAR Scanning: Using advanced LiDAR scanners, we capture millions of data points from your project site, creating a dense and dimensionally accurate 3D point cloud. This non-intrusive process rapidly gathers comprehensive data of complex environments and geometries.
Intelligent Data Processing: Our skilled technicians then process the raw point cloud data. This critical step involves cleaning, aligning, and segmenting the data to ensure it is free of noise and accurately registered, preparing it for a seamless transition into the modeling phase.
Precise BIM & CAD Modeling: The refined point cloud data is then expertly transformed into a precise and intelligent 3D model, with a Level of Detail (LOD) up to 500. The final output is a robust CAD or BIM file that accurately reflects the as-built conditions, ready for as-built documentation, facility management, and as a foundational element for Digital Twin creation.

At Triangle Engineers Ltd. our services include:

Key Advantages of Scan to BIM with TEL

Integrating our Scan to BIM service into your project workflow offers numerous benefits:

Unmatched Accuracy: Capture as-built conditions with millimeter-level precision, minimizing errors.
Enhanced Efficiency: Significantly reduce the time and labor required for site surveys and measurements compared to traditional methods.
Informed Decision-Making: Provide all stakeholders with an accurate understanding of the existing site, facilitating better planning, and collaboration.
Foundation for Digital Twins: The created models serve as the perfect starting point for developing a dynamic Digital Twin of your facility for ongoing management and operational efficiency.
Risk Mitigation: Identify potential clashes and constructability issues early in the design phase, before they become on-site problems.

Empower Your Project with TEL's Expertise
